High Speed Double Station Blow Molding Machine 1 Head Agriculture Bottle Extrusion
-
High Light
high speed Double Station Blow Molding Machine
,1 head Double Station Blow Molding Machine
,Agriculture bottle extrusion blow molding machine
-
MaterialPE,PP,EVA,ABS,PS
-
Max Capacity5L
-
ProductPlastic Agriculture Bottle
-
Machine TypeU Type
-
Layer2 Layers
-
StationDouble
-
Place of OriginCHINA
-
Brand NameSHUANGLI
-
CertificationISO, CE
-
Model NumberSLBU-65
-
Minimum Order Quantity1 SET
-
PricePrice negotiation.
-
Packaging DetailsStandard export package
-
Delivery Time20 woking day
-
Payment TermsL/C, T/T
-
Supply Ability100 Set per month
High Speed Double Station Blow Molding Machine 1 Head Agriculture Bottle Extrusion
High Speed 2 Layer Double Station 1 Die head Blow Molding Machine for Plastic Agriculture Bottle
1: this machine is suitable for the production of 200ML -5L plastic hollow products,
2: Servo Hydraulic System includes Servo Head Lifting, Servo Die Head, Servo Parison Control System, Servo Blow Pin, Servo Clamping Unit and Servo Carriage'
3 As long as the value of each segment of the current temperature value is clicked in the temperature parameter setting screen, the temperature trend graph of each segment will be automatically popped up, which reflects the fluctuation of each segment of the temperature during the heating process, and can be adjusted according to the change of the trend graph. The PID parameters for each temperature control, which makes the heating temperature more correct. Click the "Back" button to enter the temperature parameter setting screen.
| SPECIFICATION | SLBU-65 | |
| MATERIAL | PE,PP,EVA,ABS,PS | |
| MAX CONTAINER CAPACITY | L | 5 |
| NUMBER OF DIE HEAD | SET | 1,2,3,4,6,8 |
| OUPUT(DRY CYCLE) | PC/HR | 1000x2 |
| MACHINE DIMENSION (LxWxH ) | MM | 4000x2300x2200 |
| TOTAL WEIGHT | TON | 6.5T |
| CLAMPING UNIT | ||
| CLAMPING FORCE | KN | 65 |
| PLATEN OPENING STROKE | MM | 220-520 |
| PLATEN SIZE(WxH) | MM | 400x430 |
| MAX MOULD SIZE(WxH) | MM | 460x430 |
| MOLD THICKNESS | MM | 255-280 |
| EXTRUDER UNIT | ||
| SCREW DIAMETER | MM | 65 |
| SCREW L/D RATIO | L/D | 25 |
| MELTING CAPACITY | KG/HR | 70 |
| BARREL HEATING POWER | KW | 15 |
| NUMBER OF HEATING ZONE | ZONE | 3 |
| EXTRUDER MOTOR RATED POWER | KW | 15 |
| DIE HEAD | ||
| NUMBER OF DIE HEATING ZONE | ZONE | 2-5 |
| POWER OF DIE HEATING | KW | 6 |
| CENTER DISTANCE OF DOUBLE DIE | MM | 130 |
| CENTER DISTANCE OF THREE DIE | MM | 110 |
| CENTER DISTANCE OF FOUR DIE | MM | 100 |
| CENTER DISTANCE OF SIX DIE | MM | 80 |
| MAX DIE-PIN DIAMETER | MM | 180 |
| POWER | ||
| MAX DRIVE POWER | KW | 18 |
| TOTAL POWER | KW | 50 |
| FAN POWER OF SCREW | KW | 2.4 |
| AIR PRESSURE | MPA | 0.6 |
| AIR CONSUMPTION | M3/MIN | 0.4 |
| AVERAGE ENERGY CONSUMPTION | KW | 18 |
Our products are sold all over the world, you can rest assured.
