1 Layer 2 Head Fully Automatic Blow Molding Machine , 1000bph Blowing Machine For Plastic Bottle

1 Layer 2 Head Fully Automatic Blow Molding Machine , 1000bph Blowing Machine For Plastic Bottle

Products - Double Station Blow Molding Machine
  • High Light

    1 layer fully automatic blow molding machine

    ,

    2 head fully automatic blow molding machine

    ,

    1000bph blowing machine for plastic bottle

  • Material
    PE,PP,EVA,ABS,PS
  • Max Capacity
    5L
  • Product
    Plastic Household Products
  • Clamping Type
    Toggle Type-U Type
  • Station
    Double
  • Die Head
    2 Heads
  • Place of Origin
    CHINA
  • Brand Name
    SHUANGLI
  • Certification
    ISO, CE
  • Model Number
    SLBU-65
  • Minimum Order Quantity
    1 SET
  • Price
    Price negotiation.
  • Packaging Details
    Standard export package
  • Delivery Time
    20 woking day
  • Payment Terms
    L/C, T/T
  • Supply Ability
    100 Set per month

1 Layer 2 Head Fully Automatic Blow Molding Machine , 1000bph Blowing Machine For Plastic Bottle

  • 1 Layer 2 Head Fully Automatic Blow Molding Machine , 1000bph Blowing Machine For Plastic Bottle
  • 1 Layer 2 Head Fully Automatic Blow Molding Machine , 1000bph Blowing Machine For Plastic Bottle
  • 1 Layer 2 Head Fully Automatic Blow Molding Machine , 1000bph Blowing Machine For Plastic Bottle
  • 1 Layer 2 Head Fully Automatic Blow Molding Machine , 1000bph Blowing Machine For Plastic Bottle
Get Price Contact Now

High Speed 1 Layer Double Station 2 Die head Blow Molding Machine for Plastic Household Products​



SLBU series:





1: this machine is suitable for the production of 200ML-5L plastic hollow products, Servo Parison Control System, Servo Blow Pin, Servo Clamping Unit and Servo Carriage



2:Machine Setting.



Status: It shows the working status of heating and the working status of the fan.



Control: It has two functions, one is disconnected, the other is running, the running means that the temperature control section works in the system, and the disconnection means that the temperature control section is disconnected from the temperature control system.



Temperature control parameter adjustment: Click “temperature control parameter adjustment” to enter the temperature control parameter adjustment screen.





SPECIFICATION SLBU-65
MATERIAL 　 PE,PP,EVA,ABS,PS
MAX CONTAINER CAPACITY L 5
NUMBER OF DIE HEAD SET 1,2,3,4,6,8
OUPUT(DRY CYCLE) PC/HR 1000x2
MACHINE DIMENSION (LxWxH ) MM 4000x2300x2200
TOTAL WEIGHT TON 6.5T
CLAMPING UNIT 　
CLAMPING FORCE KN 65
PLATEN OPENING STROKE MM 220-520
PLATEN SIZE(WxH) MM 400x430
MAX MOULD SIZE(WxH) MM 460x430
MOLD THICKNESS MM 255-280
EXTRUDER UNIT 　
SCREW DIAMETER MM 65
SCREW L/D RATIO L/D 25
MELTING CAPACITY KG/HR 70
BARREL HEATING POWER KW 15
NUMBER OF HEATING ZONE ZONE 3
EXTRUDER MOTOR RATED POWER KW 15
DIE HEAD 　
NUMBER OF DIE HEATING ZONE ZONE 2-5
POWER OF DIE HEATING KW 6
CENTER DISTANCE OF DOUBLE DIE MM 130
CENTER DISTANCE OF THREE DIE MM 110
CENTER DISTANCE OF FOUR DIE MM 100
CENTER DISTANCE OF SIX DIE MM 80
MAX DIE-PIN DIAMETER MM 180
POWER 　
MAX DRIVE POWER KW 18
TOTAL POWER KW 50
FAN POWER OF SCREW KW 2.4
AIR PRESSURE MPA 0.6
AIR CONSUMPTION M3/MIN 0.4
AVERAGE ENERGY CONSUMPTION KW 18

1 Layer 2 Head Fully Automatic Blow Molding Machine , 1000bph Blowing Machine For Plastic Bottle 0



1 Layer 2 Head Fully Automatic Blow Molding Machine , 1000bph Blowing Machine For Plastic Bottle 1
