High Speed 200ml Plastic Extrusion Blow Moulding Machine Water Pot PE

High Speed 200ml Plastic Extrusion Blow Moulding Machine Water Pot PE

Products - High Speed Blow Molding Machine
  • High Light

    200ml plastic extrusion blow moulding machine

    ,

    high speed plastic extrusion blow moulding machine

    ,

    water pot PET blow moulding machine

  • Material
    PE,PP,EVA,ABS,PS
  • Max Capacity
    5L
  • Product
    Plastic Water Pot
  • Color
    Double
  • Die Head
    1 Head
  • Station
    Double Station
  • Place of Origin
    CHINA
  • Brand Name
    SHUANGLI
  • Certification
    ISO, CE
  • Model Number
    SLBU-65
  • Minimum Order Quantity
    1 SET
  • Price
    Price negotiation.
  • Packaging Details
    Standard export package
  • Delivery Time
    20 woking day
  • Payment Terms
    L/C, T/T
  • Supply Ability
    100 Set per month

High Speed 200ml Plastic Extrusion Blow Moulding Machine Water Pot PE

  • High Speed 200ml Plastic Extrusion Blow Moulding Machine Water Pot PE
  • High Speed 200ml Plastic Extrusion Blow Moulding Machine Water Pot PE
  • High Speed 200ml Plastic Extrusion Blow Moulding Machine Water Pot PE
  • High Speed 200ml Plastic Extrusion Blow Moulding Machine Water Pot PE
Get Price Contact Now

High Speed 1 Die Head Blow Molding Machine for Plastic Water Pot with Double Colors



1: this machine is suitable for the production of 200ML- 5L plastic hollow products, the use of curved elbow lock system, low energy consumption, the center of the lock, the lock force, speedF aster, run more smoothly.



2: Check the equipment related equipment for leaks or water leakage.
Before the machine works, clean the machine first, and clean and maintain the mold at the beginning and end of work.
The blow molding machine starts to run for half an hour. After running for a period of time, if there is no problem, then officially enter the production.





SPECIFICATION SLBU-65
MATERIAL 　 PE,PP,EVA,ABS,PS
MAX CONTAINER CAPACITY L 5
NUMBER OF DIE HEAD SET 1,2,3,4,6,8
OUPUT(DRY CYCLE) PC/HR 1000x2
MACHINE DIMENSION (LxWxH ) MM 4000x2300x2200
TOTAL WEIGHT TON 6.5T
CLAMPING UNIT 　
CLAMPING FORCE KN 65
PLATEN OPENING STROKE MM 220-520
PLATEN SIZE(WxH) MM 400x430
MAX MOULD SIZE(WxH) MM 460x430
MOLD THICKNESS MM 255-280
EXTRUDER UNIT 　
SCREW DIAMETER MM 65
SCREW L/D RATIO L/D 25
MELTING CAPACITY KG/HR 70
BARREL HEATING POWER KW 15
NUMBER OF HEATING ZONE ZONE 3
EXTRUDER MOTOR RATED POWER KW 15
DIE HEAD 　
NUMBER OF DIE HEATING ZONE ZONE 2-5
POWER OF DIE HEATING KW 6
CENTER DISTANCE OF DOUBLE DIE MM 130
CENTER DISTANCE OF THREE DIE MM 110
CENTER DISTANCE OF FOUR DIE MM 100
CENTER DISTANCE OF SIX DIE MM 80
MAX DIE-PIN DIAMETER MM 180
POWER 　
MAX DRIVE POWER KW 18
TOTAL POWER KW 50
FAN POWER OF SCREW KW 2.4
AIR PRESSURE MPA 0.6
AIR CONSUMPTION M3/MIN 0.4
AVERAGE ENERGY CONSUMPTION KW 18

High Speed 200ml Plastic Extrusion Blow Moulding Machine Water Pot PE 0
